Ercolina HB60 - Minimum Distance Between Bends

-30-
05/2021HB60
.394 10 NA NA
.472 12 NA NA
.591 15 NA NA
.630 16 NA NA
.709 18 NA NA
.787 20 NA NA
.945 24 NA NA
1.023 26 NA NA
1.102 28 NA NA
1.181 30 NA NA
1.259 32 NA NA
1.417 36 2.362 60
1.811 46 3.149 80
2.204 56 3.740 95
2.637 67 3.937 100
3.228 82 3.937 100
3.543 90 4.330 110
3.937 100 4.330 110
4.133 105 4.330 110
4.409 112 4.330 110
4.724 120 5.511 140
5.118 130 5.511 140
5.708 145 5.905 150
6.692 170 5.905 150
7.283 185 5.905 150
7.480 190 5.905 150
8.858 225 5.905 150
10.236 260 6.299 160
11.811 300 6.299 160
Radius of Minimum Distance
Center Former Between Bends
Inches Metric Inches Metric
Radius of Minimum Distance
Center Former Between Bends
Inches Metric Inches Metric
Minimum Distance Between Bends
By Center Line Radius
Min.
Size CLR Former part # Counterbend #
Wall
¾″ 2.6 .035 153R067T0750 154T0750
⅞″ 2.6 .035 153R067T0875 154T0875
1″ 3.2 .035 153R082T1000 154T1000
1¼″ 4.4 .035 153R112T1250 154T1250
1½″ 5.9 .049 153R150T1500 154T1500
1¾″ 6.7 .065 153R170T1750 154T1750
“Large Radius” Tube kit only #TUBEKIT2
HB60-M2 with “Large Radius” tube kit
Part# HB60-M2T
HB60-T with “Large Radius” tube kit
Part# HB60-TT
Min.
Size CLR Former part # Counterbend #
Wall
¾″ 2.6 .035 153R067T0750 154T0750
⅞″ 2.2 .065 153R056T0875 154T0875
1″ 2.6 .065 153R067T1000 154T1000
1¼″ 3.2 .083 153R082T1250 154T1250
1½″ 3.9 .083 153R100T1500 154T1500
“Small Radius” Tube kit only #TUBEKIT2SR
HB60-M2 with “Small Radius” tube kit
Part# HB60-M2TSR
HB60-T with “Small Radius” tube kit
Part# HB60-TTSR
Min.
Size CLR Former part # Counterbend #
Wall
½″ 1.8 .109 153R046P0500 155P0500
¾″ 2.2 .113 153R056P0750 155P0750
1″ 2.6 .133 153R067P1000 155P1000
1¼″ 3.5 .140 153R090P1250 155P1250
1½″ 3.9 .145 153R100P1500 155P1500
Tube kit only #TUBEKIT2
HB60-M2 with pipe kit Part# HB60-M2P
HB60-T with pipe kit Part# HB60-TP
