4.4. Preparing the tube
● Verify that the dimensions of the tube/profile match the tooling mounted on machine;
● Tube dimensions and type of material are correct for tooling and bending
● Deburr inner and outer edges of the material to be bent
● Tooling gripping area clean and degreased.
4.5. Controls
The HB60 machine also has:
● General power supply switch;
● Emergency button;
● Start button;
● Speed selector;
● Foot pedal.
General power supply switch
To power machine, rotate selector from “OFF - 0” position to “ON - 1” position. This operation sends
electrical power to all electrical and safety devices. Electrical motor of the hydraulic control unit will only
start after pressing the reset button.
Emergency stop button
Pressing the emergency stop button will stop all movement. The emergency stop button is fitted with an
automatic locking system once pressed remains in position. The machine cannot be reset in this phase.
The emergency button is released by rotating it in the direction indicated by the embossed arrow.
Start button
Release emergency stop button by rotating it in the direction indicated by arrow, press the start button to
restart the machine and restart operation.
Figure 9 - Hexagonal Shaft
