ergoline SUN SELECT 1400 - Cleaning or replacing UV lamps in the base

Cleaning and maintenance
10/2013 1014906-00 Operating instructions – 47/76
7.9 Cleaning or replacing UV lamps in the
base
– Lift up the acrylic panel and then remove the lamp covers and the parti-
tion: see page 37.
Replacing lamps: see page 44.
Changing the chip card: see page 43.
The assembly is the same process in reverse order.
When assembling the device please note:
– You must ensure that the recesses are at the foot end when you fit the
partition.
– Lift the acrylic up slightly and then close it.
7.10 Cleaning or replacing the UV lamps in
the side section
– Removing the side section panel: see page 41.
– Remove the lamp cover.
Replacing lamps:
UV low pressure lamps: see page 44.
UV high pressure lamps and filter panels: see page 45.
Changing the chip card: see page 43.
