Cleaning and maintenance
10/2013 1014906-00 Operating instructions – 49/76
– Remove the ninth low pressure lamp in the canopy so that you can then
access the facial tanner's low pressure lamp starter.
The assembly is the same process in reverse order.
When assembling the device please note:
– Support the canopy panel with one hand so that it does not fall down.
– Replace and retighten the screws. Replace the middle screw first and
then the outer screws.
7.12 Cleaning or replacing the UV lamps
and filter panels in the shoulder
tanner
– If an enclosed tanning tunnel is fitted: Remove the screws and then re-
move the tanning tunnel.
– Remove one screw from each one.
– Remove both housings and carefully lay them aside.
Changing the UV high pressure lamps: see page 45.
