The maximum charging current flows if the temperature of the battery is
between 5°C and 40°C. Avoid battery temperatures below 0°C while charging.
Fig. 21
-25-
Attention!
The charging time is approximately 10 hours. The battery pack is only fully
charged when the LED indication light on the charger is permanently shining
green!
Note!
During charging, the battery pack always has to be in a horizontal position
(cover always upside). Never place the battery pack in lateral or upright
position.
You achieve the longest life span, if the battery pack is always charged
immediately after it was used and if it is only stored fully charged.
