10.2 Replacing the ChainLance
1. Step
Cut off the strap in front of the white
roll and fix it with an adhesive tape to
the coil. Pull out the rest of the strap
remained in the strapping system
through the head piece of the
ChainLance and dispose it.
-61-
2. Step
(There are 2 options)
Option 1
Set the pallet width at the display of
the strapping system to 1m and drive
out the ChainLance until the joint of
the reversing sledge folds up and
locks into this position.
Fig. 86
Fig. 87
