2. General
-6-
After having parked the strapping system you have to lock up the brakes of
the two guide rolls (Fig.1a) on the strap side to avoid that the system is rolling
away accidentally.
Fig. 1
The strapping system can be pushed in an upright position with the two hand
grips (Fig.1). For pushing it you must release the brakes of the two guide rolls
on the strap side (Fig.1a).
2.2 Parking the strapping system
2.1 Moving the strapping system
Operating instructions
Guide roll with
parking brake
Handles
Fig. 1a
