-35-
Fig. 31
2. Step
Open the sliding window (31a).
After opening the sliding window,
3. Step appears automatically.
3. Step
Fold down the pivot arm with the red
circular disk until its final stop.
Fig. 32
Fig. 33
31a
Place a new strap coil onto the red
circular disk, that the strap uncoils in
the counter-clockwise direction when
looking down on the roll.
Note!
Do not yet remove the tape or adhesive tape, which fix the strap on the coil!
