4. Step (installation)
Push the ChainLance all the way back into the strapping system so that you can
see the groove of the length adjusting belt.
5. Step
Push the new length adjusting belt into the small groove below the groove for
the ChainLance.
-71-
6. Step
The further installation is done in the reversed order of the dismantling.
Fig. 109
Fig. 110
Attention!
Make sure that the length adjusting belt is inserted into the lower groove and
that it does not slide into the upper groove of the ChainLance.
