4. Step
The tensioning and sealing of the strap is different
according to the set mode (manual, semi-automatic or
automatic mode)
See to this „Setting mode of operation“ page 26
4.1 Manual tensioning and sealing
Pull the tensioning button until the required tension
force is reached (see page 26, chapter 6.5).
Thereafter, press the round welding button to weld
both straps and to cut off the upper one.
4.2 SEMI-Semi-automatic tensioning and sealing
Pull the tensioning button until the pre-set tension
force is reached. Afterwards, both straps will be
automatically welded and the upper strap will be cut
off. You can also weld the straps manually at any time
by pressing the welding button even if the pre-set
tension force was not reached.
4.3 Automatically tensioning and welding*
By a brief pulling (touching) of the tensioning button
once, the sealing process (tensioning and welding) will
be activated. Once the set tension force has been
reached, the straps are automatically welded and the
upper strap is cut off.
Fig. 64
Fig. 65
- 49 -
* This operating mode AUTO = Fully automatic strapping is factory blocked! Activation only through your
ErgoPack service partner possible.
Warning!
Strap tensioning or strapping, danger of jamming and crushing
Do not place hands or other body parts between the strap and the packaged
goods during the strapping process. Ensure that there are no other persons in
the hazard zone.
For an emergency stop in the case of danger (trapped person):
To release the strap tension (before welding), actuate the rocker lever, the
tensioning or welding button. After welding, cut the strap using a tool (strap
cutter).
