CCDarraycameraOptoLineOL80..
7.7.2 Conguring the 2nd measured value:
7.7.2.1 Setting the CAN address
➜Callupthesetupeditor.
➜Enterthecameradevicenumberinparameter0.
1 for measured value 1 (right sensor)
➜Enterthecameragroupnumberinparameter1.
0 for measured value 1
➜Enterthedeviceandgroupnumberforthesecondmeasured
valueinparameter47(subaddress).
0.2 in parameter 47 for measured value 2 (left sensor)
➜Entera1inparameter3(reset),thenchangeparameterstoiniti-
atethereset.
7.7.2.2 Determining the operating mode
➜Enterthedevicenumberforthesecondmeasuredvalueinpa-
rameter0.
2 for measured value 2
➜Enterthegroupnumberforthesecondmeasuredvalueinparam-
eter1.
0 for measured value 2
➜Settheoperatingmodeforthesecondmeasuredvalueinparam-
eter6
"1"=contrastingedge
"2"=centerbetweentwocontrastingedges
1 for measured value 2
➜Enterthecontrastingedgenumberbywhichmeasuringorguiding
istobeperformedinparameter7.Theprecedingsignindicates
thedirectionofcounting:
 Thefollowingappliesforcamerasmountedinthedirectionof
right webtravel:
Nopre-sign-directionofcountingfromoutsidetoinside.
Negativepre-sign-directionofcountingfrominsidetooutside.
 Thefollowingappliesforcamerasmountedinthedirectionof left
webtravel:
Nopre-sign-directionofcountingfromoutsidetoinside.
Negativepre-sign-directionofcountingfrominsidetooutside.
1 for measured value 2
➜Enterthesecondcontrastingedgenumberinparameter8(onlyif
cameraoperatingmode2isset).
No entry for measured value 2
7.7.2.3 Emergency guiding
➜Ifnecessaryenterthesensoraddressthatistoperformemergen-
cyguidinginparameter9.
no entry for measured value 2
 If the camera is only to output one measured value it is now
ready for operation.
