Erhardt+Leimer OL 80 - Page 21

BEA--220265-EN-04 BPage21
CCDarraycameraOptoLineOL80..
➜EntercameradevicenumberinParameter0.
➜EntercameragroupnumberinParameter1.
➜Checkparameter17.Toensurethatthecameraisproperlycali-
brated,makesurethatthecorrectlenssizeisselected: 
  1=24mm(OL8024)
  2=28mm(OL8028)
  3=50mm(OL8050)
➜EnterthetemplatewidthinParameter18.
➜Entera6(standardcalibration)inparameter3thenchangepa-
rameterstoinitiatethecalibrationroutine.Duringcalibration,both
halvesoftheLEDbaronthearraycamerawillashalternately
(approx.5secs).DuringcalibrationtworedLEDsonthesensor
keywilllightuponE+LcommanddeviceDO10...
- Ifcalibrationisnotsuccessful,everysecondLEDwillashonthe
cameraLEDbar.Inaddition,anerrormessagewillbedisplayed
inparameter5.
- Ifcalibrationissuccessful,aresetwillbeinitiatedautomatically.
ThentheLEDbaronthearraycameraindicatesthepositionof
thewebinthemeasuringrange.ThetworedLEDsonthesensor
keyofE+LcommanddeviceDO10..goout.
➜Checkparameter5additionally.
➜Ifcalibrationisnotsuccessful,(errorcode.4.or.5.),cleartheer-
rorandrepeatcalibration.
➜Ifcalibrationissuccessful(errorcode.3.,calibrationok),select
parameter22.Parameter22indicatestheentirecamerameasur-
ingrange(2048Pixel)inmillimeters.
Thelimitedmeasuringrange(step7.7)maybedeterminedac-
cordingtothefollowingequation.
➜Quitsetupmode.Entera1inparameter3,thenchangeparam-
eters.After2seconds,setupmodeisquit.
..5. errorcode  errorcode::
 Unitsindicateexposureerrors
 ..0=optimumexposure
 ..1=soiled
 ..2=under-exposed
 ..3=over-exposed
 Tensindicatecameraoperatingstatus
 .1.=emergencyguiding
 .2.=noresult
 .3.=Calibration ok
 .4.=calibrationerror:noedge
 .5.=calibrationerror:onlyoneedge
 Hundredsindicatecameracalibratingstatus
 1..=notcalibrated
setmeasuringrange(mm)=
Valueofparameter22xvalueofparameter11
2048
