24
GB
- from -100 to 100% for two control
outputs.
CC
CC
C Out 1 cycle time (in seconds).
This parameter is only available when
Pb is not 0.
Span: from 1 to 200 s.
C2C2
C2C2
C2 Out 2 cycle time (in seconds).
C2 is only available if Pb is not 0 and P5
is 5.
Span: from 1 to 200 s.
rCrC
rCrC
rC Relative Cooling gain.
This is skipped if Pb = 0 (ON/OFF action)
or P5 is not 5.
Span: from 0.20 to 1.00
OLPOLP
OLPOLP
OLP Dead band/Overlap between H/C outs (in
% of the proportional band).
“OLP” is skipped if Pb = 0 (ON/OFF
action) or P5 is not 5.
A negative value shows a dead band
while a positive value shows an overlap.
Span: from -20 to 50%.
rLrL
rLrL
rL Set point low limit (in eng. units).
Span: from min. range value (P2) to rH.
Note: when rL value has been chenged,
if the SP and SP2 value are lower than
the new rL value, thay will be alligned to
the new rL value.
rHrH
rHrH
rH Set point high limit (in eng. units).
Range:from rL to full scale value (P3).
Note: when rH value has been chenged,
if the SP and SP2 value are higher than
the new rH value, thay will be alligned to
the new rH value.
OLHOLH
OLHOLH
OLH Out maximum limit (in % of the out).
Span:
- From 0 to 100 when the instrument is
configured with one control out.
- From -100 to 100 when the instrument
is configured for two control outs.
tOLtOL
tOLtOL
tOL Duration of the out power limiter (in
minutes).
Available only if Pb is not 0.
Span: from 1 to 540 min. Above this limit,
the display shows "
InfInf
InfInf
Inf" and the
limitation is always entered.
Note: Parameter tOL can be modified but
the new value will only become operative
at the next instrument start up unless the
new value is
InfInf
InfInf
Inf.
