4T.08 Recommended Cutting Speeds With Exposed Tip
CutMaster® 60i With Exposed Tip Type Material: Mild Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per
Minute)
Standoff Plasma Gas
Pressure*
Flow (SCFH) Pierce Pierce
Height
Inches mm (Cat.
No.)
Volts
(VDC)
(Amps) Inches Meters Inches mm psi bar Plasma Total** Delay
(Sec)
Inches mm
0.036 0.9 9-8208 104 40 340 8.64 0.19 4.8
Set to the
central
region on
the pressure
dial. This is
illuminated
green when
selected.
55 170 0.00 0.2 5.1
0.06 1.5 9-8208 108 40 250 6.35 0.19 4.8 55 170 0.10 0.2 5.1
0.075 1.9 9-8208 108 40 190 4.83 0.19 4.8 55 170 0.30 0.2 5.1
0.135 3.4 9-8208 110 40 105 2.67 0.19 4.8 55 170 0.40 0.2 5.1
0.188 4.8 9-8208 113 40 60 1.52 0.19 4.8 55 170 0.60 0.2 5.1
0.25 6.4 9-8208 111 40 40 1.02 0.19 4.8 55 170 1.00 0.2 5.1
0.375 9.5 9-8208 124 40 21 0.53 0.19 4.8 55 170 NR NR NR
0.500 12.7 9-8208 123 40 11 0.28 0.19 4.8 55 170 NR NR NR
0.625 15.9 9-8208 137 40 7 0.18 0.19 4.8 55 170 NR NR NR
CutMaster® 60i With Exposed Tip Type Material: Stainless Steel
Type Plasma Gas: Air Type Secondary Gas: Single Gas Torch
Thickness Tip Output Amperage Speed (Per
Minute)
Standoff Plasma Gas
Pressure*
Flow (SCFH) Pierce Pierce
Height
Inches mm (Cat.
No.)
Volts
(VDC)
(Amps) Inches Meters Inches mm psi bar Plasma Total** Delay
(Sec)
Inches mm
0.036 0.9 9-8208 103 40 355 9.02 0.125 3.2
Set to the
central
region on
the pressure
dial. This is
illuminated
green when
selected.
55 170 0.00 0.2 5.1
0.05 1.3 9-8208 98 40 310 7.87 0.125 3.2 55 170 0.00 0.2 5.1
0.06 1.5 9-8208 98 40 240 6.10 0.125 3.2 55 170 0.10 0.2 5.1
0.078 2.0 9-8208 100 40 125 3.18 0.125 3.2 55 170 0.30 0.2 5.1
0.135 3.4 9-8208 120 40 30 0.76 0.187 4.8 55 170 0.40 0.2 5.1
0.188 4.8 9-8208 124 40 20 0.51 0.187 4.8 55 170 0.60 0.2 5.1
0.25 6.4 9-8208 122 40 15 0.38 0.187 4.8 55 170 1.00 0.2 5.1
0.375 9.5 9-8208 126 40 10 0.25 0.187 4.8 55 170 NR NR NR
