ESAB CUTMASTER 60i
Manual 0-5488 INTRODUCTION
2-3
2.04 Power Supply Specifications
3 Phase
60i 3 Phase Power Supply Specifications
Input Power 400 VAC, 3 Phase, 50/60 Hz
3 Phase Input Power Cable Power Supply includes 9' Three Phase 14 AWG 4/C input cable with plug..
Output Current 10 - 60 Amps, Continuously Adjustable
Power Supply Gas Filtering Ability Particulates to 5 Microns
Maximum Inlet Pressure 125 PSI (8.6 bar)
60i Power Supply Duty Cycle *
Ambient Air Temperature
Duty Cycle Ratings @ 40° C (104° F)
Operating Range 0° - 50° C
Rating
All Units
Duty Cycle 50% 60% 100%
Current
60 Amps 50 Amps 40 Amps
DC Voltage
126 122 119
* NOTE: The duty cycle will be reduced if the primary input power (AC) is low or the output voltage (DC) is higher than
shown in this chart.
** NOTE: The calculated RSCE value based on final measurements was 275. The equipment complies with IEC 61000-
3-12 provided that the short circuit power (SSC) is equal to or greater than 1385560.47 at the interface point between
the user supply and the public system. It is the responsibility of the installer, or user of the equipment to ensure, by
consultation with the distribution network operator if necessary, that the equipment is connected to a supply with a short-
circuit power SSC greater than or equal to 1385560.47.
60i Cut Capacity
Recommended Pierce Maximum
15.86mm (5/8") 15.86mm (5/8") 38mm (1 1/2")
Generator Recommendations
When using generators to power the 60i Plasma Cutting System, the following ratings are a minimum and are to
be used along with the ratings listed above.
60i Generator Specifications
Generator Output Rating 60i Output Current Arc Characteristic
15 kW 60A Full
12 kW
60A Limited
45A Full
10 kW
45A Limited
30A Full
NOTE!
Due to circuitry, age and condition two generators with the same ratings
may produce different results. Adjust the amperage accordingly.
