57
Table 6-7. Descriptions for SHL Command
Syntax Description
SHL<m><s><nnnnn>
SHL command is used to set high or low limit in counts for
compare function.
<m>
is a necessary parameter for specifying the high or low limit.
numeric number “0” is to set low limit, “1” is to set high limit.
<s>
is a sign symbol for the limit, can be set as “+” or “-“.
<
nnnnn
> is a five-digit decimal number from “00000” to “50000”.
Example 1: “SHL1+10234”
Range High limit to be
1000.0 V +1023.4V
500.00V +102.34V
50.000V +10.234 V
Example 2: “SHL0-09876”
Range Low limit to be
1000.0 V - 0987.6V
500.00V - 098.76V
50.000V - 09.876 V
