Esoteric N-05XD User Manual

26
Volume display setting
VOLDP>***
This sets the units used to show the volume on the display.
STEP
This shows the volume in steps.
This can be adjusted from 0 to 100 in 0.5steps.
dB1
This shows the volume in decibels.
This can be set to −∞ and −95.0 to +24.0dB in 0.5dB increments.
dB2
This shows the volume in decibels.
This can be set to −∞ and −95.0 to 0.0dB in 0.5dB increments.
Analog audio output connector setting
LOUT>***
Use this to select the analog audio output (LINE OUT) connectors to
be used.
o By default, the setting is XLR2.
ESLA
Analog audio signals are output as ES-LINK Analog (ESL-A)
through the XLR connectors.
o These connections use ordinary XLR cables, but the signals are
transmitted in a unique format, so this setting should only be
used with compatible devices.
o See page9 for more about ES-LINK Analog (ESL-A).
XLR2
Analog audio signals are output through the XLR connectors with
pin 2HOT.
XLR3
Analog audio signals are output through the XLR connectors with
pin 3HOT.
RCA
Analog audio signals are output through the RCA connectors.
Automatic display dimming setting
DPaOFF>***
Use this to set the display to darken automatically.
o By default, the setting is ON.
o If the OEL display is left on with the same indication for a long
time, brightness irregularities can occur. For this reason, we rec-
ommend that you set the automatic display dimming function to
ON.
ON
If no operation is conducted for ten minutes, the display automati-
cally turns off.
OFF
The display will not turn off automatically.
o If no operation is conducted for ten minutes, the display will
dim to DIMMER1 brightness to protect it from excessive wear.
Automatic power saving setting
APS>***
If there is no input from the selected input source for the set time, the
unit will enter standby mode automatically.
o By default, the setting is OFF.
o The input sources that are not selected have no effect on auto-
matic power saving.
OFF
The automatic power saving function is disabled.
30m
30 minutes
60m
60 minutes
90m
90 minutes
120m
120 minutes
MENU 1 (continued)

Esoteric N-05XD Specifications

General

Type	Network DAC / Preamplifier
Analog Outputs	XLR, RCA
DSD Support	DSD512
Digital Inputs	Ethernet
Analog Inputs	RCA
Headphone Output	6.3mm
Supported Audio Formats	DSD, FLAC, ALAC, WAV, AIFF, MP3, AAC
DAC Chip	ES9038PRO
Network Features	Ethernet, Wi-Fi
Frequency Response	5Hz
Total Harmonic Distortion	0.0007% (1kHz)
Dimensions	445mm x 131mm
PCM Support	44.1/48/88.2/96/176.4/192/352.8/384kHz (16/24/32-bit)
