Esoteric N-05XD User Manual

34
Specifications
Digital audio inputs
XLR ................................................................. 1
Input level ................................................. 5.0Vpp
Input impedance ........................................... 110Ω
Input signal formats
Linear PCM (AES/EBU)
32–192kHz, 16-bit, 24-bit
DSD (ES-LINK1, ES-LINK2, DoP)
2.8MHz
RCA ................................................................ 2
Input level ................................................0.5Vpp
Input impedance ........................................... 75Ω
Input signal formats
Linear PCM (IEC 60958)
32–192kHz, 16-bit, 24-bit
DSD (DoP) ............................................ 2.8MHz
Optical digital ...................................................... 2
Input level ........................ −24.0dBm to −14.5dBm peak
Input signal formats
Linear PCM (IEC 60958)
32–192kHz, 16-bit, 24-bit
DSD (DoP) ............................................ 2.8MHz
USB ....................................................... 1 (Type B)
USB 2.0 or higher recommended
Input signal formats
Linear PCM ....................................... 44.1–384kHz
16-bit, 24-bit, 32-bit
DSD
2.8MHz, 5.6MHz, 11.2MHz, 22.5MHz
ETHERNET .......................................................... 1
(1000BASE-T)
Input signal formats
Linear PCM .............................. 44.1–384kHz (stereo)
16-bit, 24-bit, 32-bit
o Only files with integer formats can be played.
DSD ............. 2.8MHz, 5.6MHz, 11.2MHz, 22.5MHz (stereo)
Supported file formats
PCM lossless ..... FLAC, Apple Lossless (ALAC), WAV, AIFF, MQA
DSD lossless ............................ DSF, DSDIFF (DFF), DoP
Compressed audio ..................MP3, AAC (m4a container)
USB drive ports ..................................................... 2
Supported file systems
FAT32, exFAT and NTFS
Single partition
USB 2.0 or higher recommended
Maximum current supply .................................... 0.5A
Input signal formats
Linear PCM .............................. 44.1–384kHz (stereo)
16-bit, 24-bit, 32-bit
o Only files with integer formats can be played.
DSD ............. 2.8MHz, 5.6MHz, 11.2MHz, 22.5MHz (stereo)
Supported file formats
PCM lossless ..... FLAC, Apple Lossless (ALAC), WAV, AIFF, MQA
DSD lossless ............................ DSF, DSDIFF (DFF), DoP
Compressed audio .................. MP3, AAC (m4a container)
Analog audio inputs
XLR ....................................................... 1 pair (L/R)
Input impedance ........................................... 50kΩ
Maximum permissible input voltage ....................... 8Vrms
RCA ...................................................... 1 pair (L/R)
Input impedance ........................................... 25kΩ
Maximum permissible input voltage ....................... 4Vrms
Clock input
BNC ................................................................ 1
Frequencies that can be input (±10 ppm) .................... 10MHz
Input impedance ............................................... 50Ω
Input level
Rectangle wave .............................. TTL level equivalent
Sine wave ......................................... 0.5 to 1.0Vrms
Analog audio outputs
XLR/ESL-A ................................................ 1 pair (L/R)
RCA ...................................................... 1 pair (L/R)
Output impedance
XLR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 220Ω
RCA ......................................................... 60Ω
Maximum output level (when analog audio output level setting is FIX)
XLR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4Vrms
RCA ....................................................... 2Vrms
Frequency response ........................... 5Hz to 75kHz (−3dB)
S/N ratio ...................................................... 110dB
Distortion ............................................ 0.003% (1kHz)
