MAGDUO Control Panel Engineering and Commissioning Manual
45
the cursor between options and the alphanumeric keypad to enter the
code. Press the ENTER key to confirm the change.
This active control will allow the engineer to change the code for
access to the engineer menus. Use the UP and DOWN keys to move
the cursor between options and the alphanumeric keypad to enter the
code. Press the ENTER key to confirm the change.
This active control will allow the engineer to view the version of panel
operating software implemented.
This active control will allow the engineer to view or change the panel
ID Number. This is the number that identifies the panel on the network.
Use the UP and DOWN keys to move the cursor between options and
the alphanumeric keypad to enter the new ID Number.
Please Note: Panel networking functions are not currently
available.
This active control will allow the engineer to view or change the panel
description. This is the name that identifies the panel on the network.
Use the LEFT and RIGHT keys to move the cursor. To change the
text, highlight the character to be changed and use the alphanumeric
keypad to change that character. After changing a character, the
cursor will automatically move to the next position. To confirm the
changes press ENTER to accept the new description.
Please Note: Panel networking functions are not currently
available.
This active control will allow the engineer to enable or disable the
weekly test timer. Use the LEFT AND RIGHT keys to toggle between
the following options. To confirm the changes press ENTER.
EXISTING CODE:3333
NEW CODE
:
:
01/09/09 20:13 ENGR
SOFTWARE VERSION
V1.04
Press Enter Key
01/09/09 20:13 ENGR
OLD PANEL ID:01
NEW PANEL ID:00
Press <> OR Esc Key
01/09/09 20:13 ENGR
EDIT PANEL NAME
NAME: MAGDUO
Press Enter Key
01/09/09 20:13 ENGR
WEEKLY TEST: OFF
1.ON 2.OFF
Press <> OR Esc Key
