Liquid Flow Regulator
Air Filter
Tank Air Inlet
Tank Liquid Outlet
Front and side view of the ESS XT
-3
TM
Spraywand Liquid Line Leader
Spraywand Air Line Leader
Air Line Female Ball Swivel
Liquid Line Female Ball Swivel
Electrical Plug
Air Compressor On/O Switch
Adjustable Air Compressor Check Relief Valve Set Between 70-100 PSI
Connects to Spraywand Liquid Line Leader
Connects to Spraywand Air Line Leader
Connects to Air Line Fe- male Ball Swivel (Red Hose)
Connects to Liquid Line Female Ball Swivel (Grey Hose)
