ESS XT-3 OWNER’S MANUAL
Table Of Contents:
Overview of ESS XT -3 Air-Assisted Electrostac Sprayer 1
Operator’s Responsibility 2
Chemical Safety Precauons 3
About the low-voltage system of the MaxCharge Spraywand 3
Safety Decals 4
Pacemaker Disclaimer 4
Front and Side view of the XT -3™ 5
Operang Instrucons 6
To clean the XT -3 aer operaon 7
REFERENCE
Spray wand 8
Air Filter 9
To clean the air lter 9
Trigger 10
To engage/disengage the trigger 10
To clean the trigger 10
Liquid Filter Assembly 11
To disassemble, clean, and reassemble the Liquid lter assembly 11
Nozzle Assembly 12
To clean nozzle assembly 12
Pre-spray check 13
Post-spray check 13
The Air & Liquid Delivery System 14
Air Compressor 14
Tank Pressure Regulator 14
The Quick Connects 15
Air connecon 15
Liquid connecon 15
Tank 16
Baeries 17
Spraying with Your ESS Sprayer 18
Preparing a Tank Mix 19
A note about operang temperatures 19
Trouble-Shoong Guide 20
Spraywand Service Parts 21
Parts List 22
Flow disk chart 22
XT -3 Service Parts 23–24
XT-3 Parts 25-33
CE Declaraon 34
Warranty 35
Yearly Spraywand Service 36
Spraywand Repair/Yearly Service Return Form 37
