ESS XT-3 - Flow Disk Chart

ESS XT-3 OWNER’S MANUAL
22
Item ESS Descripon Quanty
1 AP-5795 Hood 1
2 NC 5764 Nozzle Cover 1
3 5771 O,Ring, Internal 1
4 AP-5694 Teon Ring 1
5 NP-5983 Nozzle body, Greenhouse
(Note: Must send Spraywand in for Repair
1
6 5770 O-ring, External 1
7 3731 Repair kit, Trigger 1
8 767 Cap, Flow Regulator 1
9 768 Adapter, 1/8”-27 FPT 1
10 1755 Orice Disk (Flow Disk) 1
11 437 Strainer, #50 Mesh 1
12 770 Body, 1/8”-27 FPT, Greenhouse 1
13 227 Filter, Air, In Line 1
14 231 Air Filter 1
15 4512 Baery, Alkaline, 9v 2
16 118 Baery Cover, Spraywand Shell 1
17 316 Screw, #6-32 x 3/8 long, Phillips SS 2
18 239 QC Plug, 1/8” MPT, Brass (Spraywand Liquid) 1
19 AS-1748 Spraywand Leader Assembly Liquid 1
20 240 QC Plug, 1/4”, 1/4” MPT, Brass (Spraywand) 1
21 AS-1749 Spraywand Leader Assembly, Air 1
22 6518 Trigger Pawl 1
23 4430 Baery Charger 1
UNIT
STYLE
TANK
SIZE
ORIFICE
NUMBER
ESS PART
NUMBER
XT
XT
3 GALLON TANK
QUART BOTTLE
#20
#40
765
766
GPS 4 GALLON TANK #30 1755
EPS 4 GALLON TANK #30 1755
TRG 4 GALLON TANK #30 1755
J SERIES 15 GALLON TANK #30 1755
BP-2.5 2.5 GALLON TANK #59 4350
BP-4 4 GALLON TANK #59 4350
Note: Use of a ow disk is crucial to the operaon of the spray
gun. If the wrong size ow disk, or no ow disk is used, then the
spray gun will not spray or charge eciently.
Flow Disk Chart
XT-3 Spraywand Service Parts
