ESS XT-3 OWNER’S MANUAL
25
Base Unit (Standard 110V)
P/N 1055: Connector
Ring—Male-Vinyl
P/N 109: Fing—
1.4” HB x 1/4” MPT—BR
P/N 1149: Check Valve
P/N 1160: Elbow—1/4” NPT—45
Deg
P/N 1222: Vibraon Insulator
P/N 1225: Switch Plate—On/O
P/N 1234: Tee—1/4” NPT—BR P/N 1480: 1/4” HB x 1/4” FPT—BR
P/N 1518: Coupling Nut, 1/4”
P/N 1519: Carriage Bolt, 1/4” - SS
P1150: Coer Pin—1/8”x1-3/4”
P/N 1221: Plug
P/N 1226: Wheel
P/N AP1199: Bracket for Hose
P/N AP1210: Handle
