Use and maintenance manual 03.01 – 22/06/201610
Upper window.
The upper window is equipped with
a system that allows for its partial
opening.
By pulling the lever, the window
begins to open up. Once the lever
has been completely turned upside
down, the window appears to be
blocked into the “open” position.
By carrying out the opposite
operation, the window gets closed.
Opening/closing the door
from outside (optional).
To lock the door - which is possible
only with the door shut - insert and
rotate the key anti-clockwise.
To unlock, rotate the key clockwise.
You open the door by pushing the
press button on the handle.
N.B. Per la portiera con
elettroserratura, consultare pag. 26.
Internal locking of the door
(optional).
Locking of the door from inside is
not possible.
Opening - guaranteed even in case
the door is locked from outside -
takes place by pushing the lever
upwards.
