INDICATION WHAT IT REPRESENTS
SOC
o
BAT
Remaining battery’s charge. This energy expressed as a residual
percentage gives a precise information about the available au-
thonomy of the vehicle. It is possible that the charge percentage
doesn’t reach 100% after the charge’s phase, especially in winter.
T
It indicates the inner temperature of the batteries housing expres-
sed in °C. If a certain temperature would be overcome, don’t worry
about the battery because it is adjusted by some security devices.
kWh
It indicates the whole energy used by the vehicle until a particular
moment. In other words, this datum indicates the level of use of
the battery.
I
It indicates the instant current absorption expressed in Ampere (A).
MESSAGES THAT CAN APPEAR ON
THE DISPLAY
FIRST LINE
IN DISPLAY
SECOND LINE
IN DISPLAY MEANING/NOTES
Recharge Birò
BAT=xxx% Empty
Battery voltage below 5% (the
messages appears repeatedly at
intervals of 20 sec. and it lasts 5
seconds)
Battery Reserve
BAT=xxx%
Battery voltage below 20% (the
messages appears repeatedly at
intervals of 20 sec. and it lasts 5
seconds)
INTERNAL ERROR
CAN COMM. LOST
CAN communication error
(it appears if there is no
communication with VCU)
USER
AUTHENTICATION User login message
VCU ERROR: C_00
CALL SERVICE Communication error with battery
VCU ERROR: C_01
CALL SERVICE
Communication error with
Kolektor
VCU ERROR: C_02
CALL SERVICE
Communication error with
GPRS/GPS unit
VCU ERROR:K1xxxx
CALL SERVICE
Error in Kolektor Master
power unit (the error code is
hexadecimal)
VCU ERROR:K2xxxx
CALL SERVICE
Error in Kolektor Slave power unit
(the error code is hexadecimal)
VCU ERROR:K3xxxx
CALL SERVICE
Error in Kolektor Archimede
power unit (the error code is
hexadecimal)
Use and maintenance manual 03.01 – 22/06/2016 33
