Use and maintenance manual 03.01 – 22/06/201644
To ll the basin, unfasten stopper A and add
the liquid until you can see it reaches the basin
neck. When you have nished, put stopper A
back on.
Be careful in placing the stopper correctly, to
prevent the liquid from pouring out.
Liquid: any kind of windshield cleaning liquid
can be used, in winter we recommend using an
anti-freeze product.
Sprays: they are placed on the arm of the win-
dshield wiper; for adjustments, use a tool like a
needle.
Level of the windshield cleaner liquid basin
WINDSHIELD WIPER BRUSH
The brush must be changed only when the windshield wiper is
turned off.
Lift arm 1, get the brush to rotate 2, press the little tongue 3 and push
the brush toward the arm until it is disengaged.
To remount it, proceed inversely.
! WARNING In case of freezing temperatures, to prevent the little mo-
tor from overheating, be sure that the brush has not been immobilised
by ice.
