Use and maintenance manual 03.01 – 22/06/2016 75
TECHNICAL DATA
SIZES AND WEIGHTS
Length 1,740 mm
Width 1,030 mm
Height 1,565 mm
Wheel base 1.250 mm
Weight of Birò Lithium Re-move 348 kg
Weight of Birò Lithium Maxi 379 kg
PERFORMANCES
Maximum permitted speed 45 km/h
Boost (to enjoy more power if needed)
Slopes to go beyond up to 20%
Sudden street radius from the center of the
outside wheel 2800 mm radius
Sudden street radius minimum diam. of steering
between walls 6 m
ELECTRIC FEATURES
2 Brushless 48V electric engines 48V
Max power 4 KW
Battery charger 220 V
Braking energy’s recover
GENERAL FEATURES
Security frame 3mm thick tubular steel
Hydraulic disc brakes 4
Green windshield with wiper system
Toughened dark-green extendable roof and rear glass
Spacious compartments and glove boxes
Reversing buzzer
* For further information please refer to the chapter “Lithium Batteries”.
