Menu reference SwitchPilot 3
No
Screen
Options
01
ADDRESS
Switch 1-4: 0001-0004
Switch 1-4: Turnout numbers outputs 1 to 4
02
ADDRESS MODE
Mode : RCN-213
Mode: RCN-213: Addressing as RCN-213.
Mode: ROCO : Addressing as ROCO.
03
OUTPUT MODE 1
Mode : Impulse
Time : 520ms
Zoom : Disabled
Mode: IMPULSE | PECO | K83 | K84 |AltFlash
Time: 130 ms | 195 ms | .. 2015 ms
Zoom: Disabled | Enabled
04
OUTPUT MODE 2
Mode : Impulse
Time : 520ms
Zoom : Disabled
Mode: IMPULSE | PECO | K83 | K84 |AltFlash
Time: 130 ms | 195 ms | .. 2015 ms
Zoom: Disabled | Enabled
05
OUTPUT MODE 3
Mode : Impulse
Time : 520ms
Zoom : Disabled
Mode: IMPULSE | PECO | K83 | K84 |AltFlash
Time: 130 ms | 195 ms | .. 2015 ms
Zoom: Disabled | Enabled
06
OUTPUT MODE 4
Mode : Impulse
Time : 520ms
Zoom : Disabled
Mode: IMPULSE | PECO | K83 | K84 |AltFlash
Time: 130 ms | 195 ms | .. 2015 ms
Zoom: Disabled | Enabled
07
FADEIN & FADEOUT
Time : 65 ms
Time: 0 ms | 65 ms .. 4160 ms
08
RAILCOM
Mode : Enabled
CH2 : Enabled
Mode: Enabled | Disabled
CH2 : Enabled | Disabled
