Esu SwitchPilot 3 51830 - Page 28

28
Menu reference SwitchPilot 3
10
INFORMATION
HW : 3.0
SW : 3.0.9
Voltage : 18.4V
HW: Hardware version of the decoder.
SW: Software version of the decoder. Update with LokProgrammer
Voltage: Supply voltage of the decoder (if necessary rail tension)
11
FEEDBACK STATE
1 2 3 4
.».»..».
12
OUTPUT STATE
1 2 3 4
CMD .».»».».
PHY .».»..».
