Navis 100 Installation Guide 7
RJ45 Pinout Information
RGBW
Pin Description
1 Data +
2 Data -
3,4,5 48 VDC
6,7,8 Return
White and Fade to Warm
In Port
Pin Description
1 GND 1*
2,6 THRU 1**
3,7 THRU 2**
4,8 THRU 3**
5 PWR 1*
*Pins 1 and 5 receive ground and power from the source or the previous
luminaire in line.
**These pins pass through power to the next luminaires in line.
Out Port
Pin Description
1,5 THRU 1
2,6 THRU 2
3,7 THRU 3
4,8 No Connection
Note:
Navis 100 RGBW luminaires are not self-terminating. You
must terminate the last luminaire in line with a 120
Ω
resistor.
An RJ45 terminator is included with each F-Drive series Chroma
Card. To purchase extra RJ45 terminators, please contact your ETC
customer service representative and request part number N4086.
