16 Navis 100 Installation Guide
Power Up Procedure
Note:
Incorrect installation of recessed luminaires may cause
output to turn on and off periodically due to built-in protection
against overheating. Leave the lamp on for several hours to check
for overheating caused by improper installation. The driver can
overheat even if the lamp is off.
1. Verify that each Navis 100 luminaire is connected to the correct
driver or driver card before you power up the luminaires.
There are three models of driver or card used with the different
models of Navis 100 luminaires. See the installation manual for
your F-Drive series driver for more compatibility information.
F-Drive series Fade to Warm drivers and driver cards are
compatible with Fade to Warm luminaires.
F-Drive series Constant Current (CC) drivers and driver cards are
compatible with White luminaires.
The F-Drive R12 Chroma Card is compatible with RGBW
luminaires.
2. Verify that the driver is plugged in to a power source.
3. Activate the Panic feature of the F-Drive series driver. Each
luminaire will light at full power.
See the installation manual for your F-Drive series driver for information
about the Panic feature and the power up procedure for the driver.
Identify
Luminaires connected to the F-Drive series drivers will respond to an
RDMidentify command by blinking on and off:500 ms on, 500 ms off,
until the identify command is ended. See the installation manual for your
F-Drive series driver for information about this RDM command.
Emergency Operation and Test
See the
F-Drive W1 Driver Installation Manual
for information about
testing the emergency system.
Update RGBW Luminaire Firmware
See the installation manual for your F-Drive series driver for information
about updating the firmware for the Navis 100 RGBW luminaire.
