Table of Contents
Navis 100 Installation Guide i
Overview
1
Document Conventions
1
Help from ETC Technical Services
2
Safety
3
Emergency System Overview
4
Navis 100 Features
4
Channel Settings for RGBW Luminaires 5
Before You Begin Installation
6
Power Disconnect Device
6
Installation Requirements
6
Wiring the Luminaires
6
RJ45 Pinout Information 7
Use of Third-Party Drivers with
Daisy-Chained Luminaires 8
Installation
9
Prepare the Ceiling
10
Spacing for Wall Wash Luminaires 10
Install a Luminaire
11
Install a Wall Wash Luminaire
13
