ETC Installation Manual
ColorSource Spot
ColorSource Spot Page 5 of 12 Electronic Theatre Controls, Inc.
Setting presets and sequences
There are twelve factory-configured presets followed by five factory-
configured sequences built into the fixture. From the Preset/Sequence menu,
press the Up and Down buttons to scroll through the list. The sequence or
preset plays immediately upon selection. All presets and sequences can be re-
recorded through an RDM device.
To re-record presets:
Step 1: Using DMX or RDM, set the desired RGB levels.
Step 2: Press the Mode button to access the Preset/Sequence menu.
Step 3: Using the Up and Down buttons, navigate to the preset
number you want to re-record.
Step 4: Hold the Mode button for three seconds to confirm the preset
selection. The user interface will show a three second count-
down. The preset number will then blink once to confirm the
preset has been recorded.
