ColorSource Spot Page 6 of 12 Electronic Theatre Controls, Inc.
It is possible to activate a known preset or sequence from a connected fixture
when DMX is not present. If a connected fixture activates a preset or sequence
that is not recognized by the Spot fixture, the Spot fixture will hold its last look.
When DMX is restored, the DMX takes priority.
Pre-configured presets
Pre-configured sequences
Adjusting the intensity of presets
Step 1: Ensure that DMX data is not present.
Step 2: Press the Mode button to access the Preset/Sequence menu,
and then press the Up and Down buttons to select the preset
that you want to edit.
Step 3: Hold the Mode button for 3 seconds. The display shows
: ##
where the number is an intensity level from , or .
Step 4: Press the Up and Down buttons to change the intensity level
of the preset in real time.
Step 5: Press the Mode button to confirm your selection and return to
the Preset/Sequence menu.
The fixture will automatically return to the Preset/Sequence menu after
5 seconds of inactivity without saving edits to the preset intensity. This cancels
unsaved changes.
Preset Name Preset Name
1 3200K White 7 Magenta
2 5600K White 8 Yellow
3Red9Orange
4 Green 10 Light Yellow
5 Blue 11 Light Blue
6Cyan12Light Pink
Sequence Name
1 Rainbow Fast
2 Rainbow Slow
3Warm Colors Fast
4 Cool Colors Fast
5Random
