Sensor+ Connect Site Map
This is the an outline of the entire Sensor+ Connect web interface.
Group + Summary + Set dimmer levels + Dimmer Check + Search
Summary • General rack status • Active presets/panic • Rack errors Levels • Set individual & ranges of dimmers to a level • Release set dimmers levels • Release all dimmers levels Dimmer Check • Set dimmer to level • Release & go to the next dimmer • Release & go to the previous dimmer • Release current dimmer Search (Defaults to Search tab) • Find dimmers in Group (many search criteria)
Status of Found Dimmers • Dimmer # / Name / Position • Control source • Level of dimmer
Configure Found Dimmers • Set individual dimmer properties • Set properties of all found dimmers
Racks & Dimmers + All racks + Add racks + Individual rack select + Search
All Racks (Defaults to Status tab) • Rack name & type • Rack power per phase & frequency • Ambient rack temperature Add Racks • Add racks to group • Delete all racks in group Individual Rack Select (Defaults to Status tab) • Status
Configure Rack • Set rack properties
Configure Dimmers • Set individual dimmer properties of selected rack
Errors • View rack errors and time stamp • Clear individual errors • Clear all errors
Search (Defaults to Search tab) • Find dimmers in Group (many search criteria)
Status of Found Dimmers • Dimmer # / Name / Position • Control source • Level of dimmer
Configure Found Dimmers • Set individual dimmer properties • Set properties of all found dimmers
Configure Rack • Set Group (system) name • Set temperature scale (F or C) • Set rack properties
Login Screen
Sensor+ Connect
Web Interface
Site Map
