ETC Source Four LED Series - Specifications

1 Installation and User Interface Overview 14
Specifications
Physical
• Rugged die-cast aluminum construction • Hanging yoke standard
• Easy-access slots for secondary lenses and standard
accessories.
• Available in black (standard), white (optional), silver, or
custom colors (contact factory)
• Advanced thermal management systems for long LED
life
• Features ultra-quiet cooling fan
• Ambient operating temperature
0 to 40 °C (32 to 104 °F)
• See Fixture Weight, page 27
• Continuous operation at 40 °C (104 °F)
Electrical
• 100V to 240V 50/60 Hz universal power input • 5 foot Neutrik PowerCon to bare-end power input lead
or parallel blade U-ground (Edison) connector
• Includes Neutrik
®
PowerCon
®
in and thru connectors
• Optional 5 foot PowerCon to 20A two pin and ground
(stage pin) or grounded 20A twistlock connector
• Up to 9 fixtures (15A max) may be linked on Power
Thru
• Requires power from non-dim source
LEDs
• 60 Luxeon Rebel LED emitters (Lustr+) • 60 Luxeon Rebel ES LED emitters (Daylight and
Tungsten)
• 33 Osram OSLON Square and 27 Luxeon Rebel LEDs
(Studio HD)
• See Note About LED Fixtures, page 16
• 50,000 hr. LED life
Optical
• Compatible with all ETC Source Four lens tubes. For
best results, use the preferred lens tubes. See
Preferred Lensing Options, page 18
Control
• DMX512-A compliant • Optional strobe channel
• DMX in and thru via 5-pin XLR connectors • Standalone, studio standalone, and console-free
presets and sequences
• Onboard user interface with a high-resolution LCD • Master/slave mode
• Multiple profile options for different levels of control • 15-bit virtual dimming engine for smooth, high-quality
theatrical fades
• Optional DMX-based fan control for predictable noise
levels
• See DMX Profile, page 30
