ETC Source Four LED Series - Menu Flow Chart; Home and Main Menus (Lustr+ and Studio HD)

A Menu Flow Chart 84
Appendix A
Menu Flow Chart
The following illustrations show each of the menus that are displayed on the Source Four
LED fixture LCD and the path to each one.
Home and Main Menus (Lustr+ and Studio HD)
To Advanced
Menu
Main Menu
DMX Start Address: 001
Quick Setups
Advanced Settings
General
HSI Reg Stnd –– Str
No Sequence is Active
4/5 Intensity
Master
System OK
No Preset is Active
Main Menu
DMX Start Address: 001
Quick Setups
Advanced Settings
Quick Setups
*General
Stage
High Impact
Studio
2/15 Hue Fine
XT Architectural
Main Menu
DMX Start Address: 001
Quick Setups
Advanced Settings
