Safety Cable
A safety cable (or other approved safety device) should be attached to the fixture housing
and wrapped around the hanging structure (pipe). An appropriate attachment loop is
provided on the protruding tab of the fixture housing. Take care to leave as little slack as
possible in the safety cable to avoid the cable catching the yoke of the fixture.
Figure-1.12 Safety Cable Loop on Fixture Housing.
Fixture Weight
Total weight depends on how the individual fixture is configured.
Model
Weight
a
a) Does not include mounting hardware.
Shipping Weight
Lbs.Kg.Lbs.Kg.
With barrel 18.3 8.3 28 12.7
Without barrel 14.3 6.5 23 10.4
Safety cable
loop
