27971-01A
7
Installation - Assembly Procedures
Unscrew the bench assembly from the
pedestals. The bench is held in place with
16 screws (5 #10 x 1/2” screws on each
side, 2 under the front lip and four #10-32
x 1/2” screws in the back). The screws are
indicated by green markings.
