Installation - Remote Connections
CAUTION
The remote connection is not designed to supply
or accept high voltage, nor can it provide power
to an external timer. The sunbed’s remote inter-
face circuitry operates on 5 volts, attempting to
connect it to any higher voltages will damage the
sunbed as well as void your warranty.
T-Max® Products
The T-Max® remote systems offer the ultimate
in sunbed control, while allowing the tanner
easy straightforward operation. Your sunbed is
configured to directly connect to this system,
including the new wireless remote system.
The circuitry inside your sunbed eliminates
the need for the T-Max® 1A or 3A when con-
necting to the T-Max® Manager series. Your
sunbed supports the auto addressing feature
of the latest T-Max® Manager models and the
following parameters: 5, 6, 7, 8, 9, 10, 15 and
23. See your T-Max® manual for descriptions
of these parameters and how they function.
REMOTE PORTS
WIRED
REMOTE
PORTS (RJ-22)
WIRELESS
REMOTE
PORT (RJ-11)
T-Max® Wireless Remote System
The T-Max® AP-900 eliminates wires in your
salon, allowing easy setup without hiring an
electrician to run wires. It also protects your
investment from damage by isolating each
unit from one another. Your sunbed arrives
“wireless ready”, which means it connects
directly to the T-Max® wireless system.
The T-Max® wireless system is available in
two configurations: AP-900 Retail and AP-900
OEM. The Retail version contains a power
adapter which plugs into a standard 110V
outlet. The OEM version gets power from the
tanning bed through the same RJ-11 cable it
uses to communicate, eliminating the need
for an outlet. Tanning beds labelled “wireless
ready” use the AP-900 OEM.
Remote System Hook-up Scenarios
Follow the diagrams on the next page to see
the many different scenarios for hooking up
your salon. If you need further assistance, call
T-Max® directly at (417) 338-5101.
