Euphonix Max Air Installation Guide

Euphonix Max Air Installation Guide Max Air Overview
15
Table 1-1 Summary of Max Air Components
Component Function Number Notes
CM404
Contains 8 faders for masters, 17-inch Touch-
screen, and the Superchannel controls.
1 required
(max)
Ethernet device
CM416
Contains 16 physical faders that control two
layers of 16 inputs.
1 required
3 full max
Ethernet device
SC261
System Computer
Master system computer 1 required Ethernet device
PC253i
Interface Computer
Computer for MC524, ML530 and MIDI I/F 1 required
Ethernet device. Connects to MC524
and up to 7 ML530s via TCC.
Connects to MIDI I/F via parallel port.
Connects to SH612 (optional) via
serial port.
PC253d
Digital Pilot
Configures DF64
1 required
(max 1)
Ethernet device. Connects to DF64
via firewire.
GP132
Input/Output and
Relay System
Provides up to 32 input/output relay closures
Optional
4 supported
MIDI device.
Connects to MIDI I/F.
MC524
Monitor Interface
Analog monitor output controller 1 required
TCC connection to Interface Pilot.
1 MA703 is required (standard).
ML530
Mic/Line Interface
24 remote-control microphone preamps 7 max
TCC connection to Interface Pilot.
1 AM713 required per ML530
DF64
Digital Frame
Performs all system DSP
1 required
(max)
The DF64 comes with its own
PC253d Digital Pilot Computer. 4
MADI In, 3 MADI Out
SH612
Studio Hub
MADI hub
optional
(1 max)
Allows 8 input and 6 output devices.
Connects to PC253i via control port.
AM713
Analog to MADI
Converter
Provides 24 Analog to MADI Converters, Ste-
reo Aux Digital Input (AES/EBU or S/PDIF
available), and Aux Stereo Analog Input.
1 required for
each ML530
specified.
Requires digital sync reference.
MA703
MADI to Analog
Converter
Provides 24 MADI to Analog Converters, Ste-
reo Aux Digital Output (AES/EBU or S/PDIF
available), and Aux Stereo Analog Output.
1 required for
use with the
MC524.
Requires digital sync reference.
DM714
AES/EBU to MADI
Converter
Provides 24 AES/EBU to MADI Converters,
Stereo Aux Digital Input (AES/EBU or S/PDIF
available), and Aux Stereo Analog Input.
Optional Requires digital sync reference.
MD704
MADI to AES/EBU
Converter
Provides 24 MADI to AES/EBU Converters,
Stereo Aux Digital Output (AES/EBU or S/PDIF
available), and Aux Stereo Analog Output.
Optional Requires digital sync reference.
FC727
Digital Format
Converter
Provides 56 channels of format converted
inputs and outputs (112 channels total). Sup-
ports MADI, AES/EBU, T-DIF, ADAT Optical,
Protools, S-DIF2, ProDigi.
Optional Requires digital sync reference.
FC726
Digital Format
Converter
Provides 56 channels of format converted
inputs and outputs (112 channels total). Sup-
ports MADI, AES/EBU, T-DIF, ADAT Optical, S-
DIF2, ProDigi.
Optional Requires digital sync reference.
