Euphonix Max Air Installation Guide

Euphonix Max Air Installation Guide Interconnecting System Components
21
Console Dimensions
Figure 2-2 Max Air Top Dimensions
Figure 2-3 Max Air Side Dimensions
0.00
0.00
35.43
16.15 0.00 22.30 0.00 24.30
5.85
29.58
1.0 1.0
0
4.39 5.85 9.83
11.42 20.83 22.42 28.50
29.58
0
1.20
2.06
3.06
6.78
8.39
16.25
75.00°
Dimensions in inches
15.625
CM416 BALANCE POINT
16.13
CM404 BALANCE POINT
