Euphonix Max Air Installation Guide Max Air Components
61
Table 3-10 FC727 SDIF Cable Wiring Specification
Connector Pin Connection Description
J1 1 J4-2
In 1+
J1 2 J4-1
In 1-
J1 3 J4-6
In 3+
J1 4 J4-5
In 3-
J1 5 J4-10
In 5+
J1 6 J4-9
In 5-
J1 7 J4-14
In 7+
J1 8 J4-13
In 7-
J1 9 NC (GND)
J1 10 J4-4
In 2+
J1 11 J4-3
In 2-
J1 12 J4-8
In 4+
J1 13 J4-7
In 4-
J1 14 J4-12
In 6+
J1 15 J4-11
In 6-
J1 16 J4-16
In 8+
J1 17 J4-15
In 8-
J1 18 J1-23
Cable ID
J1 19 J1-23
Cable ID
J1 20 NC
Cable ID
J1 21 NC
J1 22 NC
J1 23 J1-18,19
GND
J1 24 NC
J1 25 NC
J1 26 J5-2
Out 1+
J1 27 J5-1
Out 1-
J1 28 J5-6
Out 3+
J1 29 J5-5
Out 3-
J1 30 J5-10
Out 5+
J1 31 J5-9
Out 5-
J1 32 J5-14
Out 7+
J1 33 J5-13
Out 7-
J1 34 J5-4
Out 2+
J1 35 J5-3
Out 2-
J1 36 J5-8
Out 4+
J1 37 J5-7
Out 4-
J1 38 J5-12
Out 6+
J1 39 J5-11
Out 6-
J1 40 J5-16
Out 8+
J1 41 J5-15
Out 8-
J1 42 NC
J1 43 NC
J1 44 NC
J1 45 NC
J1 46 NC
J1 47 NC
J1 48 NC
J1 49 NC
J1 50 NC
















Notes:
J1,J2,J3 = DB-50 male
J4 = DB-50 male
J5 = DB-50 female
Jx-x
denotes twisted pair
Jx-x
In and Out are from the FC727's perspective.

