Euphonix Max Air Installation Guide

Euphonix Max Air Installation Guide Max Air Components
58
Table 3-7 Common DB-50 Connector Pinout and Usage With Third-party Devices
Pin #
Common Connector
(DB50 Female)
SDIF usage TDIF usage ProDigi usage ADAT usage ProTools
1
In 1+ In 1+ NC In 1+ In 1/2 In 1/2+
2
In 1- In 1- In 1/2 In 1- NC In 1/2-
3
In 2+ In 3+ NC In 3+ In 3/4 In 3/4+
4
In 2- In 3- In 3/4 In 3- NC In 3/4-
5
In 3+ In 5+ NC In 5+ In 5/6 In 5/6+
6
In 3- In 5- In 5/6 In 5- NC In 5/6-
7
In 4+ In 7+ NC In 7+ In 7/8 In 7/8+
8
In 4- In 7- In 7/8 In 7- NC In 7/8-
9
GND GND GND GND GND GND
10
In 5+/GP In A In 2+ NC In 2+ Error In ICR_WC+
11
In 5- In 2- NC In 2- NC ICR_WC-
12
In 6+/GP In B In 4+ NC In 4+ User0 In ICR_BC+
13
In 6- In 4- NC In 4- NC ICR_BC-
14
In 7+/GP In C In 6+ NC In 6+ User1 In ICR_SD+
15
In 7- In 6- NC In 6- NC ICR_SD-
16
In 8+/GP In D In 8+ NC In 8+ Mstr/Slv IN ICR_AD+
17
In 8- In 8- NC In 8- NC ICR_AD-
18
Cable ID2 0 (tie to pin 23) 0 (tie to pin 23) 0 (tie to pin 23) 1 (NC) 1 (NC)
19
Cable ID1 0 (tie to pin 23) 1 (NC) 1 (NC) 0 (tie to pin 23) 0 (tie to pin 23)
20
Cable ID0 1 (NC) 0 (tie to pin 23) 1 (NC) 0 (tie to pin 23) 1
21
Bit Clk In+ NC NC Bit Clk In+ Bit Clk In Bit Clk In+
22
Bit Clk In- NC NC Bit Clk In- NC Bit Clk In-
23
GND GND GND GND GND GND
24
Word Clk In+ NC In LR Clk Word Clk In+ Word Clk In Word Clk In+
25
Word Clk In- NC NC Word Clk In- GND Word Clk In-
26
Out 1+ Out 1+ NC Out 1+ Out 1/2 Out 1/2+
27
Out 1- Out 1- Out 1/2 Out 1- NC Out 1/2-
28
Out 2+ Out 3+ NC Out 3+ Out 3/4 Out 3/4+
29
Out 2- Out 3- Out 3/4 Out 3- NC Out 3/4-
30
Out 3+ Out 5+ NC Out 5+ Out 5/6 Out 5/6+
31
Out 3- Out 5- Out 5/6 Out 5- NC Out 5/6-
32
Out 4+ Out 7+ NC Out 7+ Out 7/8 Out 7/8+
33
Out 4- Out 7- Out 7/8 Out 7- NC Out 7/8-
34
Out 5+/GP Out A Out 2+ FS0 out Out 2+ Mute Out NC
35
Out 5- Out 2- NC Out 2- NC NC
36
Out 6+/GP Out B Out 4+ FS1 out Out 4+ NC NC
37
Out 6- Out 4- NC Out 4- NC NC
38
Out 7+/GP Out C Out 6+ Emph Out Out 6+ NC NC
39
Out 7- Out 6- NC Out 6- NC NC
40
Out 8+/GP Out D Out 8+ NC Out 8+ NC NC
41
Out 8- Out 8- NC Out 8- NC NC
42
Bit Clk Out+ NC NC Bit Clk Out+ Bit Clk Out Bit Clk Out+
43
Bit Clk Out- NC NC Bit Clk Out- GND Bit Clk Out-
44
GND GND GND GND GND GND
45
Word Clk Out+ NC Out LR Clk Word Clk Out+ Word Clk Out NC
46
Word Clk Out- NC NC Word Clk Out- GND NC
47
Extra In/GP In E+ NC NC NC DVCO In NC
48
Extra In/GP In E- NC NC NC NC NC
49
NC NC NC NC Vcc NC
50
GND GND GND GND GND GND
