Table 3-9 FC727 Pro Tools Cable Wiring Specification
Notes:
J1 = DB-50 male
J2 =50-pin high density SCSI-2-style female
Jx-x denotes twisted pair
Jx-x
In and Out are from the FC727's perspective.

Connector Pin Connection Description
J1 1 J2-17
In 1/2+
J1 2 J2-42
In 1/2-
J1 3 J2-16
In 3/4+
J1 4 J2-41
In 3/4-
J1 5 J2-1
In 5/6+
J1 6 J2-26
In 5/6-
J1 7 J2-18
In 7/8+
J1 8 J2-43
In 7/8-
J1 9 J2-2 GND
J1 10 J2-5
ICR_WC+
J1 11 J2-30
ICR_WC-
J1 12 J2-3
ICR_BC+
J1 13 J2-28
ICR_BC-
J1 14 J2-21
ICR_SD+
J1 15 J2-46
ICR_SD-
J1 16 J2-23
ICR_AD+
J1 17 J2-48
ICR_AD-
J1 18 NC
Cable ID
J1 19 J1-23
Cable ID
J1 20 NC
Cable ID
J1 21 J2-19
Bit Clk In+
J1 22 J2-44
Bit Clk In-
J1 23 J1-19,J2-13 GND
J1 24 J2-11
Word Clk In+
J1 25 J2-36
Word Clk In-
J1 26 J2-7
Out 1/2+
J1 27 J2-32
Out 1/2-
J1 28 J2-8
Out 3/4+
J1 29 J2-33
Out 3/4-
J1 30 J2-25
Out 5/6+
J1 31 J2-50
Out 5/6-
J1 32 J2-24
Out 7/8+
J1 33 J2-49
Out 7/8-
J1 34
NC
J1 35
NC
J1 36
NC
J1 37
NC
J1 38
NC
J1 39
NC
J1 40
NC
J1 41
NC
J1 42 J2-9
Bit Clk Out+
J1 43 J2-34
Bit Clk Out-
J1 44 J2-38 GND
J1 45
NC
J1 46
NC
J1 47
NC
J1 48
NC
J1 49 NC
J1 50 J2-27 GND

















