Euphonix Max Air Installation Guide

Euphonix Max Air Installation Guide Max Air Components
45
MADI Out (BNC): Outputs the digital audio signal.
• 1–24: Analog inputs
• 25–26: Aux analog inputs
• 27–28: Aux digital inputs
NOTE: 28 channels are always transmitted; dual channels are not used.
Trim Pots: Four detented trim pots, accessed from the front panel, adjust the analog input lev-
el of channels 1–8, 9–16, 17–24, and auxiliary analog in 3 dB steps between +6 and +27 dBU.

Euphonix Max Air Specifications

General

Brand	Euphonix
Model	Max Air
Category	Music Mixer
Language	English
