GPIO mapping
Issue C
69
SUPER IO pin mapping
There is SCH3114 super IO used on PROTEUS. Following table shows connection some
of the SUPER IO pins.
SUPER IO GP pin number Signal Description
GP61 GPIO3 Connected to J22
pin A67
GP54 GPIO4 Connected to J22 pin A85
GP56 GPIO5 Connected to J22 pin A93
GP57 GPIO6 Connected to J22 pin B54
GP50 GPIO7 Connected to J22 pin B57
GP51 GPIO8 Connected to J22 pin B63
GP31 GPIO9 Connected to J6 pin 15
GP46 GPIO10 Connected to J6 pin 16
GP14 COM_BATLOW# Connected to J22 pin A27
GP60 COM_WDT Connected to J22 pin B27
GP67 GPS_SHDN# GPS power shutdown
GP62
UART1_SHDN# RS232 transceiver
shutdown
GP34 SIO_SLOT0_PRESENT# Connected to J22 pin A49
GP37 SIO_SLOT1_PRESENT# Connected to J22 pin B48
