11
Electrical properties
Powerline input 1-phase, 230 V, 32 A, 50 Hz. 3-phase, 400 V, 16 A, 50 Hz.
Charging power 7.4 kW (1-phase - 32 A). 11 kW (3-phase - 16 A).
Charge mode Mode 3 (IEC 61851)
Fixed charging cable Type 2 plug (IEC 62196-2).
Number of xed
charging cables
1.
Charging cable length 4.5 m or 7.5 m.
Installation wiring
16 A installation input
terminals: 1 - 6 mm².
32 A installation input
terminals: 1 - 10 mm².
Metering (only applies
to Audi Wallbox pro)
MID-certied kWh meter
Safety and certication
Upstream installation
protection
Minimum dedicated 1-phase 32 A (32 A station) or 3-phase 16 A
(16 A station) upstream circuit breaker and at minimum RCD type
A (30 mA AC). Check local installation requirements if additional
measures are required.
Static power limitation Via DIP-switches.
Dynamic power
limitation
Via CT coils – optional comfort feature.
Earth leakage sensor
(ELS)
6 mA DC
Ground loss monitor
Physical connection monitoring, without ground quality
monitoring.
CT coils supported
Invasive / non-Invasive - 40 A - 200 A,
brands: VAC, LEM, and Nidec.
See chapter Set DIP-switches (chapter 7) for the supported
models.
Operating temperature
range
-30 °C - +50 °C.
Storage temperature
range
-30 °C - +85 °C.
Operating humidity Max. 95 % - non-condensing.
Maximum installation
height
Max. 4000 m above sea level.
Enclosure ratings IP54 (IEC 60529), IK10 (IEC 62262).
Technical specications
