12
Safety Class
Safety Class I (the wallbox is equipped with a ground terminal for
safety) and overvoltage Category III.
Power supply input
EV Supply equipment permanently connected to AC supply net-
work.
Normal Environmental
conditions
Outdoor use.
Access Equipment for locations with non-restricted access.
Connectivity (Only applies to Audi Wallbox plus and Audi Wallbox pro)
Authorization RFID (ISO 14443, ISO 15693).
Wi-Fi 2.4 / 5 GHz, only WPA2 (IEEE802.11 a - ax)
Ethernet Via RJ45 connection, 10/100 Mbit/s / 100BASE TX (IEEE 802.3u)
Mobile network 2G / LTE
Communication proto-
col to Elli Backend
OCPP 2.0.0
Communication pro-
tocol to Home Energy
Management System
EEBus.
Local conguration via Conguration Manager
Physical properties
Housing Polycarbonate.
Status indication HMI (Human Machine Interface): LED based HMI
Front panel Polycarbonate and hardened glass.
Bezel Acrylonitrile Styrene Acrylate (ASA).
Mounting bracket Steel (zinc plated).
Dimensions (W x H x D) 297 mm x 406 mm x 116 mm.
Weight
1-phase 32 A station with 4.5 m charging cable ~ 6 kg.
1-phase 32 A station with 7.5 m charging cable ~7 kg.
3-phase 16 A station with 4.5 m charging cable ~ 6 kg.
3-phase 16 A station with 7.5 m charging cable ~ 7 kg.
Mounting method
Stationary equipment, mounted on walls (preferred method),
poles or equivalent positions – surface mounted.
Color Platinum gray with electric white bezel.
