7. Lay the backrest on its back, as shown.
For Canadian Models ONLY
8. Remove no-back booster insert from base.
Push in both tabs
A
on sides of no-back booster insert
and slide insert out of base, as shown.
10. Remove crotch strap from bottom of base.
Turn crotch strap anchor sideways and push it through
the seat shell to remove, as shown.
Note: Remove seat pad from base for easier access (see
page 53).
9. Remove shoulder belt clip.
Reattaching the Backrest Reattaching the Backrest
General
6. Attach harness
straps to splitter
plate.
Attach the loop at the
end of each harness strap
onto the splitter plate.
IMPORTANT: Make sure
both harness straps are
installed completely on the
splitter plate, as shown.
A
To Next Page
